Facade elements for ventilation in the window reveal

The integration of ventilation solutions in the window reveal offers clear advantages when it comes to discreet appearance, high sound insulation and maximum design freedom. With our LUNOtherm façade element, LUNOS provides a sophisticated concept that combines ventilation in the window reveal with the requirements of modern architecture and efficient living space ventilation. In contrast to conventional outer wall ducts, placement in the reveal enables virtually invisible air routing that requires no visible grilles on the façade. This is a decisive advantage, especially for buildings with strict design specifications, such as listed buildings or high-quality plaster façades.



Facade elements

LUNOtherm

For ventilation in the window reveal with particularly high sound insulationn
» view Product
Facade elements

9/SD-LS: Sound absorber

For increased sound insulation in the LUNOtherm
» view Product
Facade elements

1/IL: Insect protction grille

For insect protection in the LUNOtherm
» view Product
Facade elements

1/VL: Bird protction grille

For bird protection in the LUNOtherm
» view Product

The soffit ventilator as a system solution

In combination with the e² heat recovery system or our exhaust air fans, the LUNOtherm becomes a complete soffit ventilator solution. The façade element takes on the function of air conduction and sound insulation, while the actual ventilator ensures controlled air exchange.

System benefits at a glance:

  • Ventilation directly in the window reveal – no visible openings on the façade
  • Energy-efficient thanks to heat recovery (e.g.  with e² or ego)
  • Sound insulation up to 75 dB through combination with 9/SD-LS
  • ETICS compatible and approved by the DIBt
  • Suitable for renovation and new builds, especially where space is limited

Soffit ventilation is particularly useful when external ventilation elements are undesirable or the external insulation should not be interrupted. By integrating it into the window reveal, a continuous insulation envelope can be created without compromising on air quality.



Technically sophisticated – architecturally restrained

It is installed directly in the window reveal. Depending on the wall structure and ETICS, the LUNOtherm can be adapted – both in terms of length and structure. The air flow is concealed by the façade element, which also acts as a sound insulation component. The extended version LUNOtherm-S+ or -G+ in combination with the 9/SD-LS module is recommended for particularly noisy environments.

Planning and architectural offices as well as energy consultancies benefit from an approved system solution with proven performance:

  • Certified according to DIBt guidelines
  • Compatible with all ETICS systems
  • Verifiable sound insulation and ventilation parameters in accordance with DIN 1946-6 and DIN 4109



Typical use cases

  • Listed buildings with strict façade regulations
  • Residential complexes in noisy surroundings (e.g. on main roads)
  • New buildings with high standards of design clarity
  • Renovations with limited structural intervention space
