The wireless screen 9/IBF-RF: Smart home control in a smart design

The wireless screen contains a new control concept and brand-new technology. The built-in control offers all modern control and regulation parameters as well as a completely new sensor system. Furthermore, the operating concept has been adapted to the changing requirements of the users.

All control and regulation systems as well as a voltage transformer are permanently installed in the new inner screen. Only a 110 - 230 V power connection is required to put the ventilation system directly into operation.

The sensor system, for example, no longer only records the interior parameters, it also registers the humidity and temperature of the outside air and adjusts the volume flows of the ventilation units independently and precisely to this.

An integrated, barely perceptible push-button on the side of the panel offers the possibility of manually intervening in the ventilation behaviour as required and desired without the need for an additional switch, a control element or even a display.

In addition to standard filters that meet national and international standard requirements, extremely high-quality filters with filter classes up to "F7" are also available.

Brand new: the radio bus system from LUNOS. Developed by LUNOS itself, without restrictions of existing systems and with a view to the future, we have integrated our own LUNOS radio bus system.

The result is a communication-safe, interference-resistant and intelligent system which fulfils all the requirements placed on modern radio systems.

Synchronisation of several systems with each other, interaction of different systems with each other, integrated radio repeater technology and much more make the technology used absolutely unique.

Dimensions 9/IBF-RF

(H x W x D): 230 mm x 185 mm x 53 mm

Art.-no. 9/IBF-RF 41 183




The wireless screen was awarded by the Plus X Award in the categories:

Highest Quality
Ease of Use
